IEEE802.3af

Compliant to IEEE802.3af which features a 1500V high voltage isolation PoE transformer and integrated high performance network filter

1GbE support

10/100/1000Mbps Ethernet and supports the full range of IEEE802.3 standards: IEEE 802.3 I, IEEE 802.3 u, IEEE 802.3 x, IEEE802.3af, IEEE802.3at

Safe and secure

Supports 44V–57V, auto-detects PSE power source with isolation circuit to help protect connected equipment from short circuit, over voltage, overcurrent and overheating.

Power Efficient

At 83% efficiency this PoE splitter is class leading and leads to its -20 to +50C operating temperature range

Link Ports

8p8c (RJ45)	1×

Cable Requirements

Recommended Cable Type	CAT5e and above
Maximum Cable Length	100m / 328ft

Network Support

Bandwidth	10/100/1000MbE
10/100 Support	Yes

Environmental

Operating Temperature	-20 to 50 °C / -4 to 122 °F
Storage Temperature	-30 to 60 °C / -22 to 140 °F
Operating Humidity (%)	10% - 90% (non-condensing)
Storage Humidity (%)	5% - 95% (non-condensing)
Altitude	2000m / 6562ft

Power Source

5V	1×
Input Power Supply	PoE (802.3.AF)

Physical Design

Construction Material	Robust plastic enclosure
U size	Zero

Width	28mm / 1.1in
Height	24mm / 0.9in
Depth	81mm / 3.20in

Flying Lead Length	190mm

Weight	0.1kg / 0.2lb

Approvals and Standards

Approvals	CE, FCC, ICES
Standards	ANSI 63.4, EN/IEC 62368-1, EN55032 /CISPR 32, EN55035/CISPR 35, EN61000-3-2, EN61000-3-3, FCC pt15B, ICES003, IEE802.3at
Other	Cal Prop 65, China ROHS, EU REACH, UK REACH

Ordering Information

Code	Description
PSU-POE-5VDC-2.4A	1GbE Power over Ethernet Splitter 12W

What's in the Box?

1× 1GbE Power over Ethernet Splitter 12W
