IEEE802.3af/at
Compliant to IEEE802.3af/at which features a 1500V high voltage isolation PoE transformer and integrated high performance network filter
1GbE support
10/100/1000Mb Ethernet and supports the full range of IEEE802.3 standards: IEEE 802.3 I, IEEE 802.3 u, IEEE 802.3 x, IEEE802.3af, IEEE802.3at.
Safe and secure
Supports 44V–57V, auto-detects PSE power source with isolation circuit to help protect connected equipment from short circuit, over voltage, overcurrent and overheating.
Power Efficient
At 90% efficiency this PoE splitter is class leading and leads to its -20 to +50C operating temperature range.
Product Specification
Power Supply (PSU-POE-12VDC-2A) Specification
Link Ports
| 8p8c (RJ45) | 1× |
|---|
Cable Requirements
| Recommended Cable Type | CAT5e and above |
|---|---|
| Maximum Cable Length | 100m / 328ft |
Network Support
| Bandwidth | 10/100/1000MbE |
|---|---|
| 10/100 Support | Yes |
Environmental
| Operating Temperature | -20 to 50 °C / -4 to 122 °F |
|---|---|
| Storage Temperature | -30 to 60 °C / -22 to 140 °F |
| Operating Humidity (%) | 10% - 90% (non-condensing) |
| Storage Humidity (%) | 5% - 95% (non-condensing) |
| Altitude | 2000m / 6562ft |
Power Source
| 12V 3-pin | 1× |
|---|---|
| Input Power Supply | PoE (802.3.AF), PoE (802.3.AT) |
Physical Design
| Construction Material | Robust plastic enclosure |
|---|---|
| U size | Zero |
| Width | 28mm / 1.1in |
| Height | 24mm / 0.9in |
| Depth | 81mm / 3.20in |
| Flying Lead Length | 190mm |
| Weight | 0.1kg / 0.2lb |
Approvals and Standards
| Approvals | CE, FCC, ICES |
|---|---|
| Standards | ANSI 63.4, EN/IEC 62368-1, EN55032 /CISPR 32, EN55035/CISPR 35, EN61000-3-2, EN61000-3-3, FCC pt15B, IEE802.3at |
| Other | Cal Prop 65, China ROHS, EU REACH, UK REACH |
Ordering Information
| Code | Description |
|---|---|
| PSU-POE-12VDC-2A | 1GbE Power over Ethernet Splitter 24W |
What's in the Box?
| 1× 1GbE Power over Ethernet Splitter 24W |
